QUINT-PS-100-240AC/24DC/10

Phoenix DIN rail-mounted switch and stabilized power supplies

Manufacturer: phoenix-contact

series introduction

# Introduction to the QUINT - PS - 100 - 240AC/24DC/10 Product Series

## 1. Overview
The QUINT - PS - 100 - 240AC/24DC/10 is a high - performance power supply product series designed to meet the demanding power requirements of various industrial and commercial applications. This series is engineered with advanced technology and high - quality components to ensure reliable and efficient power conversion.

## 2. Key Features

### Input Voltage Range
- It can accept an input voltage ranging from 100V to 240V AC. This wide input voltage range makes it suitable for use in different regions around the world, where the mains voltage may vary. Whether in countries with a standard 110V AC supply or those with a 230V AC supply, the QUINT - PS - 100 - 240AC/24DC/10 can operate effectively without the need for additional voltage conversion equipment.

### Output Voltage and Current
- The series provides a stable output voltage of 24V DC. This is a commonly used voltage level in industrial automation, control systems, and many other applications. With an output current capacity of 10A, it can deliver a significant amount of power, making it capable of powering multiple devices simultaneously. For example, it can support several sensors, actuators, and small - to - medium - sized control units in an industrial production line.

### High Efficiency
- These power supplies are designed with high - efficiency topologies. They can convert the input AC power to DC power with minimal energy loss. High efficiency not only reduces operating costs by consuming less electricity but also helps in reducing heat generation. Less heat means a longer lifespan for the power supply and the connected components, as excessive heat can degrade the performance and reliability of electronic devices.

### Advanced Protection Mechanisms
- **Over - voltage Protection (OVP)**: In case of an abnormal increase in the output voltage, the OVP feature will automatically activate to protect the connected devices from damage. It ensures that the output voltage does not exceed a safe level, preventing potential harm to sensitive electronic components.
- **Over - current Protection (OCP)**: If the load draws more current than the rated 10A, the OCP mechanism will kick in. It can either limit the current or shut down the output to prevent overheating and damage to the power supply and the connected equipment.
- **Short - circuit Protection (SCP)**: In the event of a short - circuit in the output circuit, the SCP feature will immediately detect it and cut off the power supply to the load. This protects both the power supply and the connected devices from the potentially dangerous effects of a short - circuit, such as excessive current flow and component damage.

### High Reliability
- The QUINT - PS - 100 - 240AC/24DC/10 series is built with high - quality components that are selected for their reliability and durability. It undergoes rigorous testing during the manufacturing process to ensure that it can operate continuously in harsh industrial environments. It has a long mean - time - between - failures (MTBF), which means that it is less likely to break down, reducing downtime and maintenance costs.

### Compact Design
- The power supplies in this series have a compact form factor, which makes them easy to install in space - constrained environments. Whether it is a control cabinet in an industrial plant or a small equipment enclosure, the QUINT - PS - 100 - 240AC/24DC/10 can be conveniently integrated without taking up too much space.

## 3. Applications

### Industrial Automation
- In industrial automation systems, the QUINT - PS -
