DRP-480-24
480W 24V 20A DIN rail power supplies for industrial applications
Manufacturer： mean-well
series introduction
# DRP - 480 - 24 Product Series Introduction
## 1. Overview
The DRP - 480 - 24 product series represents a cutting - edge and highly reliable line of power supply solutions designed to meet the diverse and demanding needs of modern electronic systems. These power supplies are engineered with precision and incorporate the latest technological advancements to ensure stable, efficient, and safe power delivery.
## 2. Key Features
### 2.1 High Power Output
The "480" in the model number indicates a substantial power output capacity of 480 watts. This high - power capability makes the DRP - 480 - 24 series suitable for powering a wide range of devices, including industrial control systems, telecommunications equipment, and high - performance computing applications. It can handle multiple loads simultaneously, providing a reliable power source for complex setups.
### 2.2 Stable Output Voltage
With an output voltage of 24 volts, the DRP - 480 - 24 series offers a consistent and stable power supply. Voltage stability is crucial for the proper functioning of electronic components, as fluctuations can lead to malfunctions, data loss, or even permanent damage. These power supplies are equipped with advanced voltage regulation circuits that maintain the output voltage within a tight tolerance range, typically ±1%, ensuring the smooth operation of connected devices.
### 2.3 High Efficiency
Efficiency is a key consideration in power supply design, as it directly impacts energy consumption and operating costs. The DRP - 480 - 24 series boasts an impressive efficiency rating of up to 90%. This high efficiency means that less energy is wasted as heat during the power conversion process, resulting in lower electricity bills and reduced environmental impact. Additionally, the reduced heat generation extends the lifespan of the power supply and other components in the system.
### 2.4 Comprehensive Protection
To safeguard both the power supply and the connected devices, the DRP - 480 - 24 series is equipped with a comprehensive set of protection features. These include over - voltage protection (OVP), which prevents the output voltage from exceeding a safe level; over - current protection (OCP), which limits the current flow to prevent damage from short - circuits or excessive loads; and over - temperature protection (OTP), which shuts down the power supply if the internal temperature rises to a dangerous level.
### 2.5 Compact Design
The power supplies in the DRP - 480 - 24 series feature a compact and space - saving design. This makes them ideal for applications where space is limited, such as in rack - mounted systems or small enclosures. Despite their small size, they are still able to deliver high - power performance, making them a versatile choice for a variety of installations.
### 2.6 Wide Input Voltage Range
The DRP - 480 - 24 series can accept a wide input voltage range, typically from 85VAC to 264VAC. This allows for use in different regions around the world with varying power grid standards. It also provides some degree of tolerance to voltage fluctuations in the input power, ensuring reliable operation even in less - than - ideal electrical environments.
## 3. Applications
### 3.1 Industrial Automation
In industrial automation systems, the DRP - 480 - 24 series can power programmable logic controllers (PLCs), sensors, actuators, and other control devices. The stable power output and comprehensive protection features ensure the reliable operation of these critical components, minimizing downtime and improving productivity.
### 3.2 Telecommunications
Telecommunications equipment, such as routers, switches, and base stations, requires a stable and efficient power supply. The high - power output and wide input voltage range of the DR
