BZV55C20
20V Zener diodes for various applications
Manufacturer： ['taiwan-semiconductor', 'dc', 'multicomp', 'microsemi', 'micro-commerical-co']
series introduction
The BZV55C20 Series is a comprehensive line of Zener diodes renowned for their precise voltage regulation and robust performance across a diverse range of applications. Designed to provide exceptional reliability, these diodes are engineered with a classic glass package that offers both durability and thermal stability, making them ideal for various electronic circuit implementations.
One of the key features of the BZV55C20 Series is its wide Zener voltage range, which typically spans from 3.3V to 200V, allowing engineers to select the appropriate diode for their specific voltage regulation needs. This versatility ensures that the series can cater to a multitude of applications, including voltage clamping, surge protection, and reference voltage generation. The series is characterized by a low dynamic impedance, which enhances its performance in maintaining consistent voltage levels under varying load conditions. Additionally, the BZV55C20 Zener diodes boast a power dissipation capability of up to 1W, accommodating both moderate and high-power applications.
The design of the BZV55C20 Series integrates a temperature coefficient that enhances stability over a wide temperature range, ensuring reliable operation in environments ranging from -55°C to +150°C. This feature is particularly beneficial in automotive and industrial applications where temperature fluctuations are common. The diodes are also designed with a high surge capability, providing an extra layer of protection against voltage spikes, which is essential in safeguarding sensitive electronic components.
Typical applications for the BZV55C20 Series include power supply circuits, where they function as voltage regulators or protection devices, as well as in consumer electronics, telecommunications equipment, and automotive electronics. Their reliability and performance make them suitable for both commercial and industrial uses, offering engineers a dependable solution for voltage management in their designs. Whether used in compact devices or larger systems, the BZV55C20 Series Zener diodes are an excellent choice for ensuring stable voltage operation and protecting circuits from overvoltage conditions.
Images for reference
BZV55C20-TP
MINIMELF Pkg Top
Image Preview
