BZT55C11

11V 5% 500mW Zener diodes in various forms

Manufacturer: ['multicomp', 'taiwan-semiconductor', 'vishay']

series introduction

The BZT55C11 Series is a comprehensive line of Zener diodes renowned for their robust performance and reliability in voltage regulation applications. Engineered to provide precise and stable reference voltages, these diodes are particularly effective in maintaining voltage levels within specified tolerances, making them essential components in various electronic circuits. The BZT55C11 Series offers a Zener voltage rating of 11 volts, along with a wide range of power dissipation capabilities, enabling their use in both low-power and high-power applications.

One of the key features of the BZT55C11 Series is its excellent temperature stability, which is crucial for applications that require consistent performance across varying environmental conditions. With a temperature coefficient that ensures minimal change in Zener voltage with temperature fluctuations, these diodes are ideal for precision applications where voltage regulation is paramount. Additionally, the series exhibits low dynamic impedance, enhancing their performance in transient response scenarios, which is critical in applications such as power supplies and voltage clamping.

The design characteristics of the BZT55C11 Series include a glass passivated junction, which not only improves reliability but also ensures better thermal stability. This makes them suitable for high-temperature environments, enhancing their longevity and operational efficiency in demanding applications. The compact DO-41 package allows for easy integration into circuit boards, making the BZT55C11 Series a preferred choice among engineers looking for space-efficient solutions.

Typical applications of the BZT55C11 Series span a diverse array of industries. They are commonly used in power management systems, where they act as voltage references and protect sensitive components from voltage spikes. Additionally, these Zener diodes find their place in consumer electronics, automotive circuits, and telecommunications, serving critical roles in voltage regulation and protection mechanisms. Their versatility, combined with reliable performance, makes the BZT55C11 Series an indispensable component in modern electronic design and engineering.
