series introduction

The AP2213M Series represents a robust line of low dropout (LDO) linear voltage regulators designed to deliver high performance and efficiency for a wide range of electronic applications. These regulators are engineered to provide a stable output voltage with minimal dropout voltage, making them particularly advantageous in battery-powered devices where maximizing battery life is critical. With a dropout voltage as low as 300 mV at full load, the AP2213M ensures that devices can operate effectively even when the input voltage approaches the output voltage, thereby extending the operational range of systems.

One of the key features of the AP2213M Series is its wide input voltage range, which typically spans from 2.5V to 6.5V, allowing it to accommodate various power supply levels. This versatility makes it suitable for a variety of applications, including consumer electronics, telecommunications, and automotive systems. The series is available in multiple output voltage options, making it easy to select the right regulator for specific circuit requirements.

The design characteristics of the AP2213M include a small footprint, typically available in SOT-23 and TO-252 packages, making it ideal for space-constrained designs. The internal circuitry is optimized to minimize quiescent current, resulting in improved efficiency and thermal performance, which is crucial for applications that demand low power consumption and heat generation. Additionally, the AP2213M Series features built-in protections such as thermal shutdown and current limiting, ensuring safe operation under various load conditions.

Typical applications for the AP2213M Series include portable devices such as smartphones, tablets, and wearable technology, where efficiency and compact design are paramount. It is also well-suited for powering analog and digital circuits, sensor modules, and RF circuits, where stable voltage regulation is essential for reliable performance. The AP2213M Series stands out in the industry for its balance of performance, efficiency, and reliability, making it an excellent choice for engineers and designers seeking high-quality voltage regulation solutions in their electronic designs.
