ADP1720
LDO regulators and evaluation boards for power management
Manufacturer： ['rochester', 'analog-devices']
series introduction
The ADP1720 Series is a high-performance low dropout (LDO) linear voltage regulator, meticulously engineered to meet the demanding requirements of modern electronic applications. This series is characterized by its ultra-low quiescent current, which significantly enhances battery life in portable devices, making it an ideal choice for applications in mobile phones, tablets, and other battery-powered equipment. With a maximum output current of 1 A and an input voltage range of 2.3 V to 5.5 V, the ADP1720 provides a stable output voltage with excellent line and load regulation, ensuring optimal performance in a variety of operating conditions.
One of the outstanding features of the ADP1720 Series is its low dropout voltage, typically as low as 130 mV at full load, which allows for efficient operation, even when the input voltage is close to the desired output voltage. This characteristic is essential for battery-operated devices where maximizing the usable battery voltage is crucial. The series also offers a wide selection of fixed output voltage options, ranging from 1.2 V to 3.3 V, catering to various design requirements without the need for external resistors.
The compact and thermally efficient package design of the ADP1720 enhances its suitability for space-constrained applications, such as wearables and IoT devices. Additionally, the series features a thermal shutdown and current limit protection, ensuring robust operation in adverse conditions. Its low noise output is particularly beneficial in noise-sensitive applications, including RF and analog signal processing circuits.
Ideal for a diverse array of industries, the ADP1720 Series finds its application in consumer electronics, telecommunications, automotive systems, and industrial automation. Whether used for powering microcontrollers, sensors, or supporting circuit components, the ADP1720 delivers exceptional reliability and efficiency, making it a key component in the design of high-performance, power-efficient electronic systems.
Images for reference
ADP1720-3.3-EVALZ
ADP1720-3.3-EVALZ
ADP1720-5-EVALZ
