ACPL-K75T
High-speed optocouplers for automotive use
Manufacturer： ['avago', 'broadcom']
series introduction
The ACPL-K75T Series represents a robust line of high-speed optocouplers designed to meet the rigorous demands of industrial applications. These optocouplers provide electrical isolation and signal transfer between input and output circuits, making them essential for ensuring safety and integrity in various electronic systems. With a unique combination of high-speed performance and excellent electrical isolation characteristics, the ACPL-K75T Series is poised to enhance the reliability and efficiency of modern electronic designs.
One of the standout features of the ACPL-K75T Series is its high-speed data transfer capabilities, with a typical propagation delay of just 20 ns. This rapid response time allows for effective signal transmission in fast-paced applications, making them ideal for use in data communication systems, automotive electronics, and industrial automation. The optocouplers also boast a high common mode transient immunity (CMTI) of up to 15 kV/µs, which significantly reduces the risk of signal distortion due to electrical noise, thus ensuring accurate data communication even in electrically noisy environments.
The design characteristics of the ACPL-K75T Series further enhance its usability. Housed in a compact, surface-mount package, these optocouplers are suitable for space-constrained applications, offering flexibility in circuit design without compromising performance. Their wide operating temperature range, from -40°C to +100°C, ensures reliable operation in diverse environments, making them a preferred choice for applications in automotive, telecommunications, and industrial control systems.
In terms of typical applications, the ACPL-K75T Series is well-suited for isolated gate driver circuits, feedback circuits in switch-mode power supplies, and signal isolation in data acquisition systems. Their ability to provide electrical isolation helps protect sensitive components from voltage spikes and transients, enhancing the overall resilience of the system. With these features and characteristics, the ACPL-K75T Series stands out as an essential component for engineers looking to develop reliable and efficient electronic systems across various industrial sectors.
