4N25SM

Single-channel transistor output optocouplers for DC signal isolation

Manufacturer: ['fairchild', 'onsemi', 'freescale']

series introduction

# Introduction to the 4N25SM Product Series

## 1. Overview
The 4N25SM product series is a remarkable line of optocouplers that play a crucial role in modern electronic circuits. Optocouplers, also known as optoisolators, are devices that transfer electrical signals between two isolated circuits by using light. The 4N25SM series offers a reliable and efficient solution for signal isolation, noise reduction, and protection against voltage spikes, making it an essential component in a wide range of applications.

## 2. Key Features

### 2.1 Electrical Isolation
One of the primary features of the 4N25SM series is its ability to provide electrical isolation between input and output circuits. This isolation is achieved through the use of an infrared light - emitting diode (LED) on the input side and a phototransistor on the output side. The LED converts the input electrical signal into light, which is then detected by the phototransistor and converted back into an electrical signal. This physical separation between the input and output circuits prevents the flow of direct electrical current, protecting sensitive components from high - voltage transients and electrical noise.

### 2.2 High Current Transfer Ratio (CTR)
The 4N25SM series typically offers a relatively high current transfer ratio. The CTR is defined as the ratio of the output collector current of the phototransistor to the input forward current of the LED. A high CTR means that a small input current can control a relatively large output current, allowing for efficient signal transfer and amplification. This feature makes the 4N25SM suitable for applications where signal strength needs to be maintained or increased.

### 2.3 Low Input Power Requirements
The input LED in the 4N25SM series has low power requirements. This means that it can be easily driven by low - power sources such as microcontrollers or other low - voltage digital circuits. The low input power consumption not only reduces the overall power consumption of the system but also makes it compatible with a wide range of low - power electronic devices.

### 2.4 Fast Response Time
These optocouplers have a fast response time, which is the time it takes for the output to change in response to a change in the input signal. A fast response time is crucial in applications where high - speed signal transmission is required, such as in communication systems and high - frequency switching circuits. The 4N25SM series can handle rapid changes in input signals, ensuring accurate and timely signal transfer.

### 2.5 Wide Operating Temperature Range
The 4N25SM series is designed to operate over a wide temperature range. This makes it suitable for use in various environmental conditions, from industrial settings with high - temperature environments to outdoor applications where temperature fluctuations can be significant. The ability to maintain stable performance over a wide temperature range ensures the reliability and durability of the optocouplers in different operating scenarios.

## 3. Package and Pin Configuration
The 4N25SM series is commonly available in a 6 - pin dual in - line package (DIP). This package is widely used in the electronics industry due to its ease of handling and compatibility with standard printed circuit boards (PCBs). The pin configuration is well - defined, with specific pins dedicated to the input LED (anode and cathode) and the output phototransistor (collector, emitter, and base). The clear pin layout simplifies the circuit design process and allows for easy integration into existing electronic systems.

## 4. Applications

### 4.1 Industrial Control Systems
In industrial control systems, the 4N25SM series is used to isolate control signals from high - voltage power circuits. This isolation protects the control circuitry from electrical noise and voltage spikes generated by motors, solenoids, and other high
