1N5242BTR

12V, 500mW Zener diodes in DO-35 package

Manufacturer: ['diodes-zetex', 'onsemi', 'synsemi', 'fairchild', 'freescale']

series introduction

The 1N5242BTR Series is a collection of Zener diodes renowned for their precision voltage regulation and robust performance in various electronic applications. These diodes are designed to provide stable reference voltages, making them an essential component in voltage regulation circuits, clamping circuits, and signal processing applications. With a nominal Zener voltage of 12 volts, the 1N5242BTR Series delivers exceptional voltage stability, ensuring that connected components operate within their specified parameters even under fluctuating power conditions.

One of the key features of the 1N5242BTR Series is its low reverse leakage current, which enhances its efficiency and reliability in applications requiring prolonged operation. The diodes are constructed using high-quality silicon material, ensuring excellent thermal stability and a wide operating temperature range of -65°C to +175°C. This thermal resilience makes the series suitable for both consumer electronics and industrial environments where temperature fluctuations can impact performance.

The design characteristics of the 1N5242BTR Series include a glass passivated package, which not only provides protection against moisture and contaminants but also ensures a high level of reliability over time. The axial-lead configuration allows for easy integration into various circuit designs, making them ideal for through-hole mounting in printed circuit boards (PCBs). This versatility enables engineers to implement the 1N5242BTR Series in diverse applications, from power supplies to automotive systems.

Typical applications of the 1N5242BTR Series include voltage regulation in power adapters, overvoltage protection in sensitive electronics, and reference voltage generation in instrumentation circuits. Moreover, they are commonly utilized in telecommunications equipment, LED lighting circuits, and consumer appliances, ensuring stable operation and enhanced performance. With their combination of reliability, versatility, and robust electrical characteristics, the 1N5242BTR Series diodes are an indispensable choice for engineers and designers seeking high-quality Zener diodes for their electronic applications.

Images for reference

DO-35
